Me Carbo Ultra Flex CO2 System
- CO2 fertilisation system for aquariums up to 400 l
- Precision pressure regulator with solenoid valve
- Suitable for disposable and refillable CO2 cylinders
- Includes Diffuser Pro L, CO2 tubing and CO2 drop checker
- Flexible CO2 supply for aquascapes and planted aquariums
Item question
We’re here for you!
Please enter your question and e-mail and we’ll contact you as soon as possible. It usually takes us up to 24 hours during business days to respond.
Thank you for your question!
Thank you, we’ll get in touch!
Close window
You already sent us a question.
Please wait a few minutes
Description
The Me Carbo Ultra Flex CO2 System is a CO2 fertilisation system for aquarium plants. It provides a reliable CO2 supply and is ideal for aquascapes and planted aquariums.
The Flex system enables precise CO2 dosing and, thanks to the included adapter, can be used with both disposable and refillable CO2 cylinders. The supplied pressure regulator is equipped with a solenoid valve for automatic night-time shut-off.
In addition to the diffuser and transparent CO2 tubing, the set also includes a CO2 drop checker with indicator solution. It continuously monitors the CO2 level through an easy-to-read colour change, making it simple to fine-tune the CO2 supply. This ensures aquarium plants receive the carbon they need for healthy growth and vibrant colours.
Note
CO2 cylinder not included.
Features
- CO2 fertilisation system for aquarium plants
- Suitable for aquariums up to 400 l
- Precision CO2 regulator with dual pressure gauges for cylinder and working pressure
- Integrated solenoid valve for automatic night-time shut-off
- Bubble counter with integrated check valve for precise CO2 dosing
- Fine needle valve for accurate adjustment of the bubble rate
- Adjustable working pressure from 0 to 6 bar
- Suitable for disposable and refillable CO2 cylinders thanks to the included adapter
- Includes diffuser, transparent CO2 tubing and CO2 drop checker with indicator solution
Application
Before commissioning, fill the bubble counter to approximately two-thirds with water. Then screw the pressure regulator onto a suitable CO2 cylinder with the cylinder valve closed and connect the CO2 tubing to the diffuser. Thanks to the included adapter, the system can be operated with both refillable and disposable CO2 cylinders.
The solenoid valve is connected to a suitable timer or CO2 controller. It opens when power is supplied and automatically shuts off the CO2 supply when the power is disconnected. This allows the CO2 supply to be conveniently synchronised with the lighting period, preventing unnecessary CO2 consumption during the night.
After slowly opening the cylinder valve, the right-hand pressure gauge displays the cylinder pressure. The desired working pressure is set using the pressure regulator, after which the CO2 flow is adjusted via the precision needle valve.
The included CO2 drop checker allows continuous monitoring of the CO2 concentration in the aquarium. The colour change of the indicator solution quickly shows whether the CO2 level is too low, optimal or too high. This makes it easy to adjust the bubble rate and maintain an ideal CO2 supply for healthy plant growth while ensuring safe CO2 levels for aquarium inhabitants.
After use, close the cylinder valve and release the remaining pressure from the system.
Technical data
| Me CO2 Regulator Ultra Solenoid Valve | |
|---|---|
| Max. inlet pressure | 150 bar |
| Outlet pressure | 0 - 6 bar, adjustable |
| Solenoid valve voltage | Input: 100–240 V / Output: 12 V DC |
| Power consumption | 2.5 W |
| Cable length | 1.1 m |
| Connection thread | W21.8, for refillable CO2 cylinders |
Dimensions
| Me CO2 Regulator Ultra | |
|---|---|
| Length | 85 mm |
| Width | 75 mm |
| Height | 105 mm |
| Me CO2 Check Glass | |
|---|---|
| Length | 45 mm |
| Width | 30 mm |
| Height | 45 mm |
| Me CO2 Diffuser Pro - L | |
|---|---|
| Length | 32,4 mm |
| Width | 32,4 mm |
| Height | 82 mm |
Cleaning
Clean the system regularly and carefully to ensure reliable operation of the diffuser and CO2 accessories.
- Shut off the CO2 supply before cleaning.
- Carefully clean the diffuser and CO2 drop checker if necessary.
- Check tubing and connections for secure fit and contamination.
After cleaning, reconnect all components securely and check the system for leaks.
Scope of delivery
- Regulator Ultra – Pressure regulator incl. solenoid valve
- Diffuser Pro L
- FlexTube CO2 tubing, 2 m
- Refillable-to-disposable adapter
- CO2 Check Glass for precise monitoring of the CO2 concentration, including 15 ml indicator solution
Product safety
Caution: Electricity
Warnings:
- Improper use may result in serious injury or property damage. Keep out of reach of children!
- Do not use oil- or grease-based lubricants – risk of explosion when in contact with pressurised CO2!
- Electrical connections must only be made by qualified persons.
- Only use with timers or controllers designed for continuous operation.
- Always disconnect from the power supply before cleaning.
General information:
- Only use with suitable CO2 cylinders (observe the maximum inlet pressure of 150 bar).
- Do not operate near open flames or heat sources.
- Operate only in well-ventilated rooms at room temperature.
- The solenoid valve must only be operated with the specified voltage.
Handling instructions:
- Only install or remove the regulator when the cylinder valve is closed.
- Never tighten with excessive force – the seals must not be damaged.
Me
Me supplies high-quality aquarium supplies. The company has more than 30 years of experience in development, purchasing and logistics. This expertise is incorporated into the continuous improvement of accessories and aquarium products in order to provide reliable and durable equipment for aquariums.
Manufacturer information
| Manufacturer | |
|---|---|
| Name | AS Aquaristik & Heimtierbedarf GmbH & Co. KG |
| Street | Gewerbering 19 |
| City | 86931 Prittriching |
| State | Bayern |
| Country | Deutschland |
| as@as-aquaristik.de | |
| Website | www.as-aquaristik.de |
General information
| Item no. |
|
| EAN | 4043366012207 |
| Weight | 1,55 kg |
| Shipping weight | 2,98 kg |
