Me CO2 Control Night Bubble Counter + Solenoid Valve
- CO2 solenoid valve with bubble counter
- Automatic night shut-off
- Integrated non-return protection
- Maximum operating pressure 6 bar
- Control via timer or pH controller
Sign in or Register
Item question
We’re here for you!
Please enter your question and e-mail and we’ll contact you as soon as possible. It usually takes us up to 24 hours during business days to respond.
Thank you for your question!
Thank you, we’ll get in touch!
Close window
You already sent us a question.
Please wait a few minutes
Description
The Me CO2 Control Night is a precise CO2 control unit for aquariums that combines a solenoid valve with an integrated bubble counter. It enables accurate control and automatic regulation of CO2 supply via a timer or pH controller, thereby promoting plant growth and stabilising water parameters. The device is intended exclusively for use in aquatics and is installed directly into the existing CO2 supply line.
The solenoid valve opens when power is supplied and automatically closes when the power is interrupted. This allows the CO2 supply to be stopped automatically during the night or dark phase, conserving energy and CO2 while preventing over-saturation when photosynthesis ceases. The integrated bubble counter with backflow protection allows for easy monitoring of the dosage, while the robust construction ensures a secure and leak-proof connection. The device operates at 12 V DC using the supplied power adapter and is rated for pressures up to 6 bar.
Thanks to its compact design and ease of use, the Me CO2 Control Night can be seamlessly integrated into existing CO2 systems. It ensures reliable, safe and efficient operation.
Features
- CO2 solenoid valve with integrated bubble counter and backflow protection
- Automatic night shut-off via timer or pH controller
- Precise regulation of CO2 supply for optimal plant growth
- Easy installation on regulators with standard connection
- Safe operation with 12 V DC low voltage
- Maximum input pressure: 6 bar
- Compact, robust design for long-term use
Application
- Before initial operation, fill the integrated bubble counter halfway with water through the side opening. This allows for visual monitoring of the CO2 flow rate during operation.
- The solenoid valve is then installed directly into the CO2 hose line (4/6 mm) using the integrated push-fit connections. The arrow marked on the housing indicates the direction of gas flow and must point towards the aquarium.
- After installation, the device is connected via the supplied power adapter to a timer or pH controller, allowing automatic control of the CO2 supply.
- When power is supplied, the solenoid valve opens and releases the CO2 flow. When the power supply is interrupted, the valve closes automatically, stopping the CO2 flow completely.
- The water level in the bubble counter should be checked regularly and topped up if necessary to ensure consistent and clearly visible bubble formation.
- The device must only be operated outside the aquarium in a dry environment. Vertical installation with the hose connections facing upwards is recommended to prevent condensation.
Dimensions
| Me CO2 Control Night | |
|---|---|
| Length | 122 mm |
| Width | 50 mm |
| Height | 22 mm |
Scope of Delivery
- Me CO2 Control Night (solenoid valve with bubble counter and backflow protection)
- Power adapter (Input: 100–240 V / Output: 12 V DC)
- User manual
Product safety
Caution: Electrical hazard
Safety Instructions:
- Improper use may cause serious injury or property damage. Keep the product out of reach of children.
- Electrical connections must only be made by qualified personnel.
- Ensure the correct voltage and connect the product only to suitable power sources.
- Use the product only with timers or controllers designed for continuous operation.
- Do not connect or operate the product with wet hands.
- The product is intended for indoor use only.
Me
Me supplies high-quality aquarium supplies. The company has more than 30 years of experience in development, purchasing and logistics. This expertise is incorporated into the continuous improvement of accessories and aquarium products in order to provide reliable and durable equipment for aquariums.
Manufacturer information
| Manufacturer | |
|---|---|
| Name | AS Aquaristik & Heimtierbedarf GmbH & Co. KG |
| Street | Gewerbering 19 |
| City | 86931 Prittriching |
| State | Bayern |
| Country | Deutschland |
| as@as-aquaristik.de | |
| Website | www.as-aquaristik.de |
General information
| Item no. |
|
| EAN | 4043366012146 |
| Weight | 0,24 kg |
| Shipping weight | 0,29 kg |
