Description
The Fluval 07 Series filters are 2019 redesigned aquarium external filters that combine performance-power, energy-efficiency and ease of use. The vertical pre-filtration stage combined with the four-chamber tower provide quick access to media as well as maximum filtration capacity for crystal clear aquarium water. The 4 different sizes are suitable for freshwater and marine aquariums from approx. 40 to 500 litres.
With a very low energy consumption of 10 W (107-207), 15 W (307) and 20 W (407), the filters of the 07 series, nevertheless, remain very powerful with a large maximum water column. In addition, every square centimetre of the available tank volume is utilised by stacking the filter media in a practical media tower. Due to the unique pre-filter, the coarse dirt is already removed mechanically before the aquarium water enters the media chambers. Its vertical position gives quick and practical access to the main chambers.
Maintenance is further facilitated by simple HUB lock clamps on the motor head. Self-priming is also triggered effortlessly on the 07 series, as the fibreglass-reinforced handle can be operated easily and without discomfort using 2 fingers. This is even possible in the aquarium cabinet. The new, ergonomically designed Aquastop valve connects securely with plastic ribbing for friction-free operation. The lever on the Aquastop valve ensures adjustable water flow. The wide range of original Fluval filter media ensures reliable cleaning of the aquarium water.
Features
- Newly revised in the 7th edition
- Angenehm leise im Betrieb durch überarbeitete, präzisionsgefertigte Pumpe
- Pleasantly quiet operation due to revised, precision-engineered pump
- Fast self-priming due to glass fibre reinforced lever
- Extremely powerful due to low-wear rotor, large filter volume and high-quality filter media
- High energy efficiency
- Controllable water flow
Scope of delivery
Filtermedia per Model
Model | 107 | 207 | 307 | 407 |
---|---|---|---|---|
Bio-Foam Max | 2 | 2 | 2 | 2 |
Bio-Foam | 2 | 2 | 2 | 2 |
Bio-Foam+ | 1 | 1 | 2 | 2 |
Bio-Terra | 1 | 1 | 2 | 4 |
Bio-Max | 1 | 1 | 2 | 2 |
Quick Clear | - | 1 | 2 | 2 |
Note
For best results, the filter media should be changed according to the respective specified intervals.
Technical Data
Fluval 07 - 107 | |
---|---|
Max. flow rate | 360 Litres per hour |
Power consumption | 10 W |
Filter Volume | 2,0 l |
Pre-Filter Volume | 0,514 l |
Canister Volume | 3,9 l |
Max. Water Column | 1,45 m |
Fluval 07 - 107 | |
---|---|
Max. flow rate | 780 l/h |
Power consumption | 10 W |
Filter Volume | 3,1 l |
Pre-Filter Volume | 0,803 l |
Canister Volume | 5,3 l |
Max. Water Column | 1,45 m |
Fluval 07 - 307 | |
---|---|
Max. flow rate | 1.150 l/h |
Power consumption | 15 W |
Filter Volume | 4,5 l |
Pre-Filter Volume | 0,803 l |
Canister Volume | 7,3 l |
Max. Water Column | 1,75 m |
Fluval 07 - 407 | |
---|---|
Max. flow rate | 1.450 l/h |
Power consumption | 20 W |
Filter Volume | 6,0 l |
Pre-Filter Volume | 1,074 l |
Canister Volume | 9,2 l |
Max. Water Column | 2,25 m |
Dimensions
Fluval 07 - 107 | |
---|---|
Length | 190 mm |
Width | 180 mm |
Height | 350 mm |
Suitable for aquariums | 40-130 l |
Fluval 07 - 207 | |
---|---|
Length | 190 mm |
Width | 180 mm |
Height | 420 mm |
Suitable for aquariums | 60-220 l |
Fluval 07 - 307 | |
---|---|
Length | 240 mm |
Width | 180 mm |
Height | 420 mm |
Suitable for aquariums | 90-330 l |
Fluval 07 - 407 | |
---|---|
Length | 240 mm |
Width | 180 mm |
Height | 490 mm |
Suitable for aquariums | 150-500 l |
Warranty conditions
There is a manufacturer's warranty (for further information and notes on the warranty see below!) on the part of the guarantor
HAGEN Deutschland GmbH & Co. KG
Lehmweg 99
105 25488 Holm
Germany
with a duration of 24 months.
The following warranty conditions apply:
"THREE (3) YEAR WARRANTY
Fluval 07 Series External Filters are warranted against defects in material and workmanship under normal aquarium usage and service for three (3) years from date of purchase. Non-replaceable and non-serviceable parts will be repaired or replaced at Hagen’s discretion, free of charge, when the complete filter is returned with all components along with a valid proof of purchase and postage paid. The warranty does not cover wear and tear parts such as the impeller assembly or motor seal ring. The warranty does not cover wear and tear or parts which have not been adequately or correctly maintained. The warranty is limited to repair or replacement only and does not cover consequential loss, loss or damage to livestock, personal property or damage to animate or inanimate objects, irrespective of the cause thereof.
This warranty is valid only under normal operating conditions for which the unit is intended. This excludes any damage caused by unreasonable use, negligence, improper installation, tampering, abuse or commercial use. Before returning the filter under warranty terms, please ensure that all setup and maintenance instructions have been followed. If you are in doubt, please contact your local aquatic specialist retailer for further advice before returning the product.
WARRANTY IS ONLY VALID WITH PROOF OF PURCHASE FROM AN AUTHORIZED FLUVAL DEALER. WARRANTY DOES NOT AFFECT YOUR STATUTORY RIGHTS."
Source: Manual
Notice:
The legal defect rights towards Aquasabi GmbH & Co. KG according to §§ 437 ff. BGB (German Civil Code) are not compromised by this warranty.
Fluval

Since 1975, Fluval has been offering advanced aquarium technology such as filters, lighting solutions and complete aquarium systems with a high degree of quality and innovation. Fluval's pioneering spirit is reflected in constantly modern products that meet the changing times and fast pace in the field of aquaristics with functionality and robustness. Fluval is not only committed to the much-loved hobby of aquaristics, but also to the preservation of the environment through coral conservation projects, species protection programmes and also works in a close context with the aquaristics community.
